Hilti TE 70-AVR Manual

*2063040*
2063040 ﻋﺮﺑﻲ 87
◀
ﺍﻋﺘﻨﻲﺟﻴﺪﺍﺑﺎﻷﺩﻭﺍﺕﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻭﺍﻟﻤﻠﺤﻘﺎﺕ.ﺍﻓﺤﺺﺍﻷﺟﺰﺍءﺍﻟﻤﺘﺤﺮﻛﺔﻣﻦﺣﻴﺚﺃﺩﺍﺋﻬﺎﻟﻮﻇﻴﻔﺘﻬﺎﺑﺪﻭﻥ
ﻣﺸﺎﻛﻞﻭﻋﺪﻡﺍﻧﺤﺼﺎﺭﻫﺎﻭﺍﻓﺤﺼﻬﺎﻣﻦﺣﻴﺚﻭﺟﻮﺩﺃﺟﺰﺍءﻣﻜﺴﻮﺭﺓﺃﻭﻣﺘﻌﺮﺿﺔﻟﻠﻀﺮﺭﻳﻤﻜﻦﺃﻥﺗﺆﺛﺮ
ﺳﻠﺒﺎﻋﻠﻰﻭﻇﻴﻔﺔﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ.ﺍﻋﻤﻞﻋﻠﻰﺇﺻﻼﺡﺍﻷﺟﺰﺍءﺍﻟﺘﺎﻟﻔﺔﻗﺒﻞﺍﺳﺘﺨﺪﺍﻡﺍﻟﺠﻬﺎﺯ.ﺍﻟﻜﺜﻴﺮﻣﻦ
ﺍﻟﺤﻮﺍﺩﺙﻣﺼﺪﺭﻫﺎﺍﻷﺩﻭﺍﺕﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﺍﻟﺘﻲﺗﻢﺻﻴﺎﻧﺘﻬﺎﺑﺸﻜﻞﺭﺩﻱء.
◀
ﺣﺎﻓﻆﻋﻠﻰﺃﺩﻭﺍﺕﺍﻟﻘﻄﻊﺣﺎﺩﺓﻭﻧﻈﻴﻔﺔ.ﺗﺘﻤﻴﺰﺃﺩﻭﺍﺕﺍﻟﻘﻄﻊﺫﺍﺕﺣﻮﺍﻑﺍﻟﻘﻄﻊﺍﻟﺤﺎﺩﺓﺍﻟﻤﻌﺘﻨﻰﺑﻬﺎﺑﺪﻗﺔ
ﺑﺄﻧﻬﺎﺃﻗﻞﻋﺮﺿﺔﻟﻠﺘﻌﺜﺮﻭﺃﺳﻬﻞﻓﻲﺍﻟﺘﻌﺎﻣﻞ.
◀
ﺍﺳﺘﺨﺪﻡﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻭﺍﻟﻤﻠﺤﻘﺎﺕﻭﺃﺩﻭﺍﺕﺍﻟﻌﻤﻞﻭﺧﻼﻓﻪﻃﺒﻘﺎﻟﻬﺬﻩﺍﻟﺘﻌﻠﻴﻤﺎﺕ.ﺍﺣﺮﺹﻓﻲﻫﺬﻩ
ﺍﻷﺛﻨﺎءﻋﻠﻰﻣﺮﺍﻋﺎﺓﺍﺷﺘﺮﺍﻃﺎﺕﺍﻟﻌﻤﻞﻭﺍﻟﻤﻬﻤﺔﺍﻟﻤﺮﺍﺩﺗﻨﻔﻴﺬﻫﺎ.ﺍﺳﺘﺨﺪﺍﻡﺍﻷﺩﻭﺍﺕﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻓﻲﺗﻄﺒﻴﻘﺎﺕ
ﻏﻴﺮﺗﻠﻚﺍﻟﻤﻘﺮﺭﺓﻟﻬﺎﻳﻤﻜﻦﺃﻥﻳﺆﺩﻱﻟﻤﻮﺍﻗﻒﺧﻄﻴﺮﺓ.
◀ﺣﺎﻓﻆﻋﻠﻰﺍﻟﻤﻘﺎﺑﺾﻭﻣﻮﺍﺿﻊﺍﻟﻤﺴﻚﻓﻲﺣﺎﻟﺔﺟﺎﻓﺔﻭﻧﻈﻴﻔﺔﻭﺧﺎﻟﻴﺔﻣﻦﺍﻟﺰﻳﺖﻭﺍﻟﺸﺤﻢ.ﺍﻟﻤﻘﺎﺑﺾ
ﻭﻣﻮﺍﺿﻊﺍﻟﻤﺴﻚﺍﻻﻧﺰﻻﻗﻴﺔﺗﺤﻮﻝﺩﻭﻥﺍﺳﺘﻌﻤﺎﻝﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻭﺍﻟﺘﺤﻜﻢﺑﻬﺎﺑﺸﻜﻞﺁﻣﻦﻓﻲﺍﻟﻤﻮﺍﻗﻒ
ﻏﻴﺮﺍﻟﻤﺘﻮﻗﻌﺔ.
ﺍﻟﺨﺪﻣﺔ
◀
ﺍﻋﻤﻞﻋﻠﻰﺇﺻﻼﺡﺃﺩﺍﺗﻚﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻋﻠﻰﺃﻳﺪﻱﻓﻨﻴﻴﻦﻣﻌﺘﻤﺪﻳﻦﻓﻘﻂﻭﺍﻻﻗﺘﺼﺎﺭﻋﻠﻰﺍﺳﺘﺨﺪﺍﻡﻗﻄﻊ
ﺍﻟﻐﻴﺎﺭﺍﻷﺻﻠﻴﺔ.ﻭﺑﺬﻟﻚﺗﺘﺄﻛﺪﺃﻥﺳﻼﻣﺔﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﺗﻈﻞﻗﺎﺋﻤﺔ.
2.2ﺇﺭﺷﺎﺩﺍﺕﺍﻟﺴﻼﻣﺔﻟﻠﻤﺜﺎﻗﺐ
ﺇﺭﺷﺎﺩﺍﺕﺍﻟﺴﻼﻣﺔﻟﺠﻤﻴﻊﺍﻷﻋﻤﺎﻝ
◀
ﺍﺣﺮﺹﻋﻠﻰﺍﺭﺗﺪﺍءﻭﺍﻗﻴﺔﻟﻸﺫﻧﻴﻦﻋﻨﺪﺍﻟﺜﻘﺐﺑﺎﻟﻄﺮﻕ.ﻟﺬﺍﻳﺮﺟﻰﻣﺮﺍﻋﺎﺓﺃﻥﺍﻟﻀﺠﻴﺞﺍﻟﺼﺎﺧﺐﻳﻤﻜﻦﺃﻥ
ﻳُﻔﻘﺪﻙﺍﻟﻘﺪﺭﺓﻋﻠﻰﺍﻟﺴﻤﻊ.
◀
ﺍﺳﺘﺨﺪﻡﺍﻟﻤﻘﺒﺾﺍﻹﺿﺎﻓﻲ.ﻓﻘﺪﺍﻥﺍﻟﺴﻴﻄﺮﺓﻳﻤﻜﻦﺃﻥﻳﺆﺩﻱﻟﻮﻗﻮﻉﺇﺻﺎﺑﺎﺕ.
◀
ﺃﻣﺴﻚﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻣﻦﻧﻄﺎﻗﺎﺕﺍﻟﻤﺴﻚﺍﻟﻤﻌﺰﻭﻟﺔﻋﻨﺪﺇﺟﺮﺍءﺃﻋﻤﺎﻝﻳﺤﺘﻤﻞﺃﻥﺗﺘﻼﻣﺲﻓﻴﻬﺎﺍﻷﺩﺍﺓ
ﺍﻟﻤﺴﺘﺨﺪﻣﺔﺃﻭﺍﻟﺒﺮﺍﻏﻲﻣﻊﺃﺳﻼﻙﻛﻬﺮﺑﺎﺋﻴﺔﻣﺨﻔﻴﺔﺃﻭﺳﻠﻚﺍﻷﺩﺍﺓﻧﻔﺴﻬﺎ.ﺣﻴﺚﺃﻥﻣﻼﻣﺴﺔﺳﻠﻚﻳﺴﺮﻱ
ﻓﻴﻪﺍﻟﺘﻴﺎﺭﺍﻟﻜﻬﺮﺑﺎﺋﻲﻳﻤﻜﻦﺃﻥﻳﻨﻘﻞﺍﻟﺠﻬﺪﺍﻟﻜﻬﺮﺑﺎﺋﻲﻟﻸﺟﺰﺍءﺍﻟﻤﻌﺪﻧﻴﺔﺑﺎﻟﺠﻬﺎﺯﻭﻳﺆﺩﻱﻟﺤﺪﻭﺙﺻﺪﻣﺔﻛﻬﺮﺑﺎﺋﻴﺔ.
ﺇﺭﺷﺎﺩﺍﺕﺍﻟﺴﻼﻣﺔﻓﻲﺣﺎﻟﺔﺍﺳﺘﺨﺪﺍﻡﺭﻳﺸﺔﺛﻘﺐﻃﻮﻳﻠﺔ
◀
ﻻﺗﻌﻤﻞﺑﺄﻱﺣﺎﻝﻣﻦﺍﻷﺣﻮﺍﻝﺑﻌﺪﺩﻟﻔﺎﺕﺃﻋﻠﻰﻣﻦﻋﺪﺩﺍﻟﻠﻔﺎﺕﺍﻷﻗﺼﻰﺍﻟﻤﺴﻤﻮﺡﺑﻪﻟﺮﻳﺸﺔﺍﻟﺜﻘﺐ.
ﻋﻨﺪﺍﻟﻌﻤﻞﺑﻌﺪﺩﻟﻔﺎﺕﺃﻋﻠﻰﻳﻤﻜﻦﺃﻥﺗﻨﺜﻨﻲﺭﻳﺸﺔﺍﻟﺜﻘﺐﺑﺴﻬﻮﻟﺔ،ﺇﺫﺍﺩﺍﺭﺕﺩﻭﻥﺗﻼﻣﺲﻣﻊﻗﻄﻌﺔﺍﻟﺸﻐﻞ،
ﻭﺗﺆﺩﻱﺇﻟﻰﻭﻗﻮﻉﺇﺻﺎﺑﺎﺕ.
◀
ﺍﺑﺪﺃﻋﻤﻠﻴﺔﺍﻟﺜﻘﺐﺩﺍﺋﻤًﺎﺑﻌﺪﺩﻟﻔﺎﺕﻣﻨﺨﻔﺾﻭﻋﻨﺪﻣﺎﺗﻜﻮﻥﺭﻳﺸﺔﺍﻟﺜﻘﺐﻣﻼﻣﺴﺔﻟﻘﻄﻌﺔﺍﻟﺸﻐﻞ.ﻋﻨﺪ
ﺍﻟﻌﻤﻞﺑﻌﺪﺩﻟﻔﺎﺕﺃﻋﻠﻰﻳﻤﻜﻦﺃﻥﺗﻨﺜﻨﻲﺭﻳﺸﺔﺍﻟﺜﻘﺐﺑﺴﻬﻮﻟﺔ،ﺇﺫﺍﺩﺍﺭﺕﺩﻭﻥﺗﻼﻣﺲﻣﻊﻗﻄﻌﺔﺍﻟﺸﻐﻞ،
ﻭﺗﺆﺩﻱﺇﻟﻰﻭﻗﻮﻉﺇﺻﺎﺑﺎﺕ.
◀ﺍﺿﻐﻂﻋﻠﻰﺭﻳﺸﺔﺍﻟﺜﻘﺐﺑﺪﻭﻥﺇﻓﺮﺍﻁﻭﻓﻲﺍﺗﺠﺎﻩﻃﻮﻟﻲﻓﻘﻂ.ﻓﻘﺪﺗﺘﻌﺮﺽﺭﻳﺸﺔﺍﻟﺜﻘﺐﻟﻼﻧﺜﻨﺎءﻭﺍﻻﻧﻜﺴﺎﺭ
ﻣﻦﺟﺮﺍءﺫﻟﻚ،ﺃﻭﻣﻦﺍﻟﻤﻤﻜﻦﺃﻥﺗﻔﻘﺪﺍﻟﺴﻴﻄﺮﺓﻋﻠﻴﻬﺎﻭﺗﺘﺴﺒﺐﻓﻲﻭﻗﻮﻉﺇﺻﺎﺑﺎﺕ.
ﺇﺭﺷﺎﺩﺍﺕﺍﻟﺴﻼﻣﺔﻓﻲﺣﺎﻟﺔﺍﺳﺘﺨﺪﺍﻡﻣﻀﺎﺭﺏﺍﻟﺘﻘﻠﻴﺐﻭﺧﻼﻃﺎﺕﺍﻟﺘﻘﻠﻴﺐ
◀
ﻻﺗﻘﻢﺑﺘﺸﻐﻴﻞﺃﻭﺇﻳﻘﺎﻑﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﺇﻻﺇﺫﺍﻛﺎﻥﻣﻀﺮﺏﺍﻟﺘﻘﻠﻴﺐﻣﻮﺟﻮﺩﻓﻲﺍﻟﻤﺎﺩﺓﺍﻟﻤﺮﺍﺩ
ﺧﻠﻄﻬﺎ.ﻭﺇﻻﻓﻘﺪﺗﻔﻘﺪﺍﻟﺴﻴﻄﺮﺓﻋﻠﻰﺍﻷﺩﺍﺓﻭﺗﺘﻌﺮﺽﻟﺨﻄﺮﺍﻹﺻﺎﺑﺔ.
2.3ﺇﺭﺷﺎﺩﺍﺕﺍﻟﺴﻼﻣﺔﺍﻹﺿﺎﻓﻴﺔﻟﻠﻤﺜﻘﺎﺏﺍﻟﻤﻄﺮﻗﻲ
ﺳﻼﻣﺔﺍﻷﺷﺨﺎﺹ
◀ﺍﻗﺘﺼﺮﻋﻠﻰﺍﺳﺘﺨﺪﺍﻡﺍﻟﻤﻨﺘﺞﻭﻫﻮﻓﻲﺣﺎﻟﺔﺳﻠﻴﻤﺔﻣﻦﺍﻟﻨﺎﺣﻴﺔﺍﻟﻔﻨﻴﺔ.
◀
ﻻﺗﻘﻢﺃﺑﺪﺍﺑﺄﻳﺔﺗﺪﺧﻼﺕﺃﻭﺗﻐﻴﻴﺮﺍﺕﻋﻠﻰﺍﻟﺠﻬﺎﺯ.
◀
ﺍﺳﺘﺨﺪﻡﺍﻟﻤﻘﺎﺑﺾﺍﻹﺿﺎﻓﻴﺔﺍﻟﻤﻮﺭﺩﺓﻣﻊﺍﻟﺠﻬﺎﺯ.ﻓﻘﺪﺍﻥﺍﻟﺴﻴﻄﺮﺓﻳﻤﻜﻦﺃﻥﻳﺆﺩﻱﻟﻮﻗﻮﻉﺇﺻﺎﺑﺎﺕ.
◀
ﺃﺛﻨﺎءﺃﻋﻤﺎﻝﺍﻟﺜﻘﺐﻗﻢﺑﺘﺄﻣﻴﻦﺍﻟﻨﻄﺎﻕﺍﻟﻮﺍﻗﻊﻋﻠﻰﺍﻟﺠﻬﺔﺍﻟﻤﻘﺎﺑﻠﺔﻟﻠﻌﻤﻞ.ﺍﻟﺸﻈﺎﻳﺎﺍﻟﻤﺘﻨﺎﺛﺮﺓﻳﻤﻜﻦﺃﻥﺗﺘﻄﺎﻳﺮ
ﻭ/ﺃﻭﺗﺴﻘﻂﻭﺗﺼﻴﺐﺍﻵﺧﺮﻳﻦ.
◀
ﺃﻣﺴﻚﺍﻟﺠﻬﺎﺯﺩﺍﺋﻤﺎﺑﻴﺪﻳﻚﻣﻦﺍﻟﻤﻘﺎﺑﺾﺍﻟﻤﻌﻨﻴﺔ.ﺣﺎﻓﻆﻋﻠﻰﺟﻔﺎﻑﻭﻧﻈﺎﻓﺔﺍﻟﻤﻘﺎﺑﺾ.
◀
ﺃﻣﺴﻚﺍﻟﺠﻬﺎﺯﻣﻦﻣﻮﺍﺿﻊﺍﻟﻤﺴﻚﺍﻟﻤﻌﺰﻭﻟﺔﻋﻨﺪﺇﺟﺮﺍءﺃﻋﻤﺎﻝﻳﺤﺘﻤﻞﻓﻴﻬﺎﺃﻥﺗﺘﻼﻣﺲﺃﺩﺍﺓﺍﻟﺸﻐﻞﻣﻊﺃﺳﻼﻙ
ﻛﻬﺮﺑﺎﺋﻴﺔﻣﺨﻔﻴﺔ.ﺣﻴﺚﺃﻥﻣﻼﻣﺴﺔﺳﻠﻚﻳﺴﺮﻱﻓﻴﻪﺍﻟﺘﻴﺎﺭﺍﻟﻜﻬﺮﺑﺎﺋﻲﻳﻤﻜﻦﺃﻥﻳﻨﻘﻞﺍﻟﺠﻬﺪﺍﻟﻜﻬﺮﺑﺎﺋﻲﻟﻸﺟﺰﺍء
ﺍﻟﻤﻌﺪﻧﻴﺔﺑﺎﻟﺠﻬﺎﺯﻭﻳﺆﺩﻱﻟﺤﺪﻭﺙﺻﺪﻣﺔﻛﻬﺮﺑﺎﺋﻴﺔ.
◀
ﺗﺠﻨﺐﻣﻼﻣﺴﺔﺍﻷﺟﺰﺍءﺍﻟﺪﻭﺍﺭﺓ-ﺧﻄﺮﺍﻹﺻﺎﺑﺔ!

Hilti TE 70-AVR Specifications

General

Category	Power Tool
Type	Rotary Hammer
Single Impact Energy	11.5 J
Hammer Drilling Diameter Range	12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)	12 - 40 mm
Dust Removal Module Available	Yes
Power Source	Corded Electric
Voltage	230 V
Drilling Mode	Hammer drilling, chiseling
Vibration Reduction	Active Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)	40 - 100 mm
Full Hammering Frequency	3510 impacts/minute
Blows Per Minute	2760 BPM
Sound Pressure Level	91 dB(A)
Tool Chuck Type	SDS-max
Tool Holder	SDS-max
Vibration Level	9.6 m/s² (Hammer drilling into concrete)
