6 English 2063040
*2063040*
For ATC to function correctly, the power tool must be free to pivot.
After the power tool has cut out due to ATC, switch it back on again by releasing the control switch
for a moment and then pressing the switch again.
3.5 Service indicator
The product is equipped with a service indicator LED.
3.5.1 Service indicator status
Status Meaning
The service indicator lights red. End of service interval – servicing is due.
The service indicator blinks red. Have the combihammer repaired by Hilti Service.
3.6 Items supplied
Combihammer, side handle, operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or at:
www.hilti.group | USA: www.hilti.com
4 Technical data
For rated voltage, rated current, frequency and/or input power, refer to the country-specific type
identification plate.
If the tool is powered by a generator or transformer, the generator or transformer’s power output must be
at least twice the rated input power shown on the rating plate of the tool. The operating voltage of the
transformer or generator must always be within +5 % and -15 % of the rated voltage of the tool.
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Weight in accordance
with EPTA
procedure 01
8.3 kg 9.5 kg 9.7 kg
Single impact energy in
accordance with EPTA
procedure 05
11.5 J 11.5 J 11.5 J
Hammer drill bits, Ø
12 mm … 55 mm 12 mm … 55 mm 12 mm … 55 mm
Ø drill bits for wood
10 mm … 32 mm 10 mm … 32 mm 10 mm … 32 mm
Ø drill bits for metal
0 mm … 20 mm 0 mm … 20 mm 0 mm … 20 mm
4.1 Noise information and vibration values in accordance with EN 60745
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure. The data given represents the main applications of the power tool.
However, if the power tool is used for different applications, with different accessory tools, or is poorly
maintained, the data can vary. This can significantly increase exposure over the total working period. An
accurate estimation of exposure should also take into account the times when the tool is switched off, or
when it is running but not actually being used for a job. This can significantly reduce exposure over the
total working period. Identify additional safety measures to protect the operator from the effects of noise
and/or vibration, for example: Maintaining the power tool and accessory tools, keeping the hands warm,
organization of work patterns.
Noise emission values
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Sound (power) level (L
WA
)
113 dB(A) 113 dB(A) 113 dB(A)
Uncertainty for the sound power level
(K
WA
)
3 dB(A) 3 dB(A) 3 dB(A)
