Page #13 background imageLoading...
Page #13 background image
*2063039*
2063039 English 9
or generator must always be within +5 % and -15 % of the rated voltage of
the tool.
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Weight
18.3 lb
(8.3 kg)
20.9 lb
(9.5 kg)
21.4 lb
(9.7 kg)
Single impact
energy in ac-
cordance with
EPTA procedure
05
11.5 J 11.5 J 11.5 J
Hammer drill
bits, Ø
1/2 in
2 3/16 in
1/2 in
2 3/16 in
1/2 in
2 3/16 in
Hammer drill
bits, Ø
12 mm
55 mm
12 mm
55 mm
12 mm
55 mm
Ø drill bits for
wood
13/32 in
1 1/4 in
13/32 in
1 1/4 in
13/32 in
1 1/4 in
Ø drill bits for
wood
10 mm
32 mm
10 mm
32 mm
10 mm
32 mm
Ø drill bits for
metal
0 in 23/32 in 0 in 23/32 in 0 in 23/32 in
Ø drill bits for
metal
0 mm 20 mm 0 mm 20 mm 0 mm 20 mm
4.1 Using extension cords
WARNING
A damaged supply cord presents a hazard! Do not touch the supply cord
or extension cord if damaged while working. Disconnect the supply cord
plug from the power outlet.
Check the appliance’s supply cord at regular intervals and have it replaced
by a qualified specialist if found to be damaged.
Use only extension cords of a type approved for the application and
with conductors of adequate gauge (cross section). The power tool
may otherwise suffer a drop in performance and the extension cord may
overheat.
Check the extension cord for damage at regular intervals.
Replace damaged extension cords.
When working outdoors, use only extension cords that are approved and
correspondingly marked for this application.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02
