Hilti TE 70-AVR User Manual

10 English 2063039
*2063039*
Recommended minimum conductor cross-section and maximum
power-cord length for 120V supply voltage
Cord AWG 16 AWG 14 AWG 12 AWG 10
Conductor cross-section 1,31
mm²
2,08
mm²
3,31
mm²
5,26
mm²
Conductor cross-section 2,58
kcmil
4,11
kcmil
6,53
kcmil
10,4
kcmil
Cord length 25 m 30 m 50 m 100 m
Cord length 75 ft 100 ft 150 ft 250 ft
5 Operation
5.1 Fitting the side handle 2
CAUTION
Risk of injury! Loss of control over the combihammer.
▶ Check that the side handle is fitted correctly and tightened securely.
Check that the clamping band is engaged in the groove provided on the
tool.
▶ Fit the side handle.
5.2 Fitting / removing the accessory tool 3
The use of unsuitable grease may cause damage to the tool. Use only
genuine Hilti grease.
Always check the accessory tool for damage and uneven wear before
each use; replace if necessary.
▶ Fit or remove the accessory tool, as applicable.
5.3 Drilling without hammer action 4
Drilling without hammer action is possible when accessory tools with a
special connection end are used. Tools of this kind are available from
the Hilti tools range.
When the keyless quick-release chuck is fitted, smooth-shank drill bits
for wood or steel, for example, can be used to drill without hammer
action.
▶
Set the function selector switch to the “Hammer drilling” position .
5.4 Mixing 4
Use the mixing paddle only with the quick-release chuck.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

Hilti TE 70-AVR Specifications

General

Category	Power Tool
Type	Rotary Hammer
Single Impact Energy	11.5 J
Hammer Drilling Diameter Range	12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)	12 - 40 mm
Dust Removal Module Available	Yes
Power Source	Corded Electric
Voltage	230 V
Drilling Mode	Hammer drilling, chiseling
Vibration Reduction	Active Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)	40 - 100 mm
Full Hammering Frequency	3510 impacts/minute
Blows Per Minute	2760 BPM
Sound Pressure Level	91 dB(A)
Tool Chuck Type	SDS-max
Tool Holder	SDS-max
Vibration Level	9.6 m/s² (Hammer drilling into concrete)
