*2063039*
2063039 English 5
Power tool use and care
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
Disconnect the plug from the power source and/or remove the
battery pack, if detachable, from the power tool before making
any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
Maintain power tools and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
Service
Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
2.2 Drill safety warnings
Safety instructions for all operations
Wear ear protectors when impact drilling. Exposure to noise can cause
hearing loss.
Use the auxiliary handle(s). Loss of control can cause personal injury.
Hold the power tool by insulated gripping surfaces, when performing
an operation where the cutting accessory or fasteners may contact
hidden wiring or its own cord. Cutting accessory or fasteners contacting
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

Other manuals for Hilti TE 70-AVR

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hilti TE 70-AVR and is the answer not in the manual?

Hilti TE 70-AVR Specifications

General IconGeneral
CategoryPower Tool
TypeRotary Hammer
Single Impact Energy11.5 J
Hammer Drilling Diameter Range12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)12 - 40 mm
Dust Removal Module AvailableYes
Power SourceCorded Electric
Voltage230 V
Drilling ModeHammer drilling, chiseling
Vibration ReductionActive Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)40 - 100 mm
Full Hammering Frequency3510 impacts/minute
Blows Per Minute2760 BPM
Sound Pressure Level91 dB(A)
Tool Chuck TypeSDS-max
Tool HolderSDS-max
Vibration Level9.6 m/s² (Hammer drilling into concrete)
