3 Product Description CPU 03
Page 18 of 38 HI 800 479 E Rev. 1.00
3.4.6.2 Network Ports Used for Ethernet Communication
UDP ports Use
123
SNTP (time synchronization between PES and remote I/O, PES and
external devices)
502 Modbus (can be modified by the user)
6010 safeethernet and OPC
6005/ 6012 If TCS_DIRECT was not selected in the HH network
8000 Programming and operation with SILworX
8004 Configuration of the remote I/O using the PES (SILworX)
34964 PROFINET endpoint mapper (required for establishing the connection)
49152 PROFINET RPC server
49153 PROFINET RPC client
Table 9: Network Ports (UDP Ports) in Use
TCP ports Use
502 Modbus (can be modified by the user)
xxx TCP SR assigned by the user
Table 10: Network Ports (TCP Ports) in Use
i
The ComUserTask can use any port if it is not already used by another protocol.
3.4.6.3 Connections for Fieldbus Communication
The 2 9-pole D-sub connectors can be accessed through the front plate of the module.
The fieldbus interfaces FB1 and FB2 can be equipped with fieldbus submodules. The
fieldbus submodules are optional and must be mounted by the manufacturer. The available
fieldbus submodules are described in the SILworX Communication Manual (HI 801 101 E).
The fieldbus interfaces are not operational without fieldbus submodule.
