HINGMED ABP-03 - Device Symbols Explanation; Chapter 4 Product Installation and Use; Battery Installation Guide

11
Night or sleeping period
Automatic measurement
Systolic pressure
Diastolic and systolic pressure values indicated
after measuring
Unit of diastolic and systolic pressure
Heart rate value indicated after measuring
Heart rate unit (times per minute)
Indicate current time when not measuring, after
powering on.
indicate battery capacity
3.2.3 Symbols
Chapter 4 Product Installation and Use
4.1 Battery installation
Install two AA batteries in battery slot located in the back of device, symbols of poles
show the orientation by which the batteries should be placed, after loading, the monitor
screen displays the following contents:
1. Incrementing dashes for two seconds;
2. Battery capacity and current time which flash 15 seconds;
Symbol Description Symbol Description
CF type applied part Series number
Manufacturer
Attention, refer to accompanying
documents
Keep away from rain
This way up
Fragile
Complying with WEEE standard
Stacking limit by number
Temperature limits
Refer to user manual
IP22
It means the device could
protected against solid foreign
objects of 12.5mm and greater,
and against vertical falling water
drop 15°
