16
Chapter 2 Measurement Procedure
MAX
→
MIN
→
AVE
→
instantaneous value
(no indication)
3. During measurement, the
MAX/MIN
key can
be used to select the value that should be
shown.
MAX: Maximum value is shown.
MIN: Minimum value is shown.
AVE:Averagevalueisshown=(maximum
value + minimum value/2)
If none of the MAX, MIN,orAVE indicators is
shown, the display shows the instantaneous
value.
4. Pressing the
HOLD
key will stop the
recording function. The
HOLD
indication
appears and the REC indication stops
flashing.
By pressing the
MAX/MIN
key in this
condition, the MAX, MIN,andAVE values
stored in the internal memory can be called
up on the display, as follows.
While
HOLD
is shown, the elapsed time is
not incremented. Also if the clamp sensor is
removed from the conductor for easier
reading, the minimum value will not return
to zero.
Pressing the
HOLD
keyoncemorecausesthe
HOLD
indication to go out. The recording
function resumes, and REC flashes again.
To Next Page
