The following options are available for the IR4000 series. Ask
your dealer or Hioki representative when ordering.
L9787 Test Lead, L9788-10 Test Lead with Remote Switch and L9788-11
Test Lead Set with Remote Switch are all exclusively designed for the
HIOKI IR4000 ANALOG M HiTESTER series. Do not use for any other
purpose.
Options
□ L9787 Test Lead (1.2 m)
□ L9787-91 Breaker Pin
(Pin length 70 mm and 48 mm from the tip has
width 2.5 mm. The rest have width 3.8 mm.)
Breaker pin for L9787.
□ L9788-10 Test Lead with Remote Switch
(1.2 m)
Test lead with MEASURE key for the line side
measurement. Measurement can be started by
pressing the key. There is a light at the tip which
can be switched on by pressing the LIGHT key on
the IR4000 Series. Earth side lead is not attached.
□ L9788-11 Test Lead Set with Remote
Switch
Set of the model L9788-10 and L9787 with an
EARTH side lead.
□ L9788-90 Tip Pin (for Model L9788-10)
Replacement Tip Pin for the L9788-10.
□ L9788-92 Breaker Pin (for Model L9788-10)
(Pin length 123 mm and 65 mm from the tip has
width 2.6 mm.)
Replacement Tip Pin for the L9788-10.
□ 9804-02 Magnetic Adapter
(Ø11 mm Corresponding standard screw: M6
Button head screw)
Adaptor for connecting a Test lead to the round
head screw by means of magnetism. The tip of
adaptor is a concave shape in order to fit the
round head screw. Put an adaptor on the tip of
the earth side lead of a L9787 Test Lead or
L9788-11 Complete Test Lead.
□ C0100 Carryingcase
