Chapter 1 Overview
The following options are available for the FT3405, FT3406
Tacho Hitester. Ask your dealer or Hioki representative when
ordering.
Options
Model, product,
and diagram
Notes
Z5003
Contact Adapter
Dimensions: Approx. 41W×107H×44D mm
(1.61"W×4.21"H×1.73"D)(excluding screw)
Mass: Approx. 46 g (1.6 oz)
*The Z5003 Contact Adapter includes
9032×1, 9033×2, and 9212×1.
9032
Metal Contact Tip
Attaches to the Z5003 Contact Adapter.
9033
Rubber Contact Tip
Attaches to the Z5003 Contact Adapter.
9212
Peripheral Ring
Attaches to the Z5003 Contact Adapter.
Outer circumference: 10 cm
Z1004
AC Adapter
For model FT3406
Rated supply voltage:100 V to 240 V
Output voltage: 5 V
Output current: 1.2 A
Mass: Approx. 69 g (2.4 oz) Plug not included.
Dimensions: Approx. 45W×58H×34D mm
(1.77"W×2.28"H×1.34"D)
Operating temperature and humidity
: 0°C to 40°C (32 to 104°F), 20 to 80%RH
Storage temperature and humidity
: -20°C to 80°C (-4 to 176°F), 10 to 95%RH
