Hioki FT3405 User Manual

Chapter 5 Specifications
40
General specifications
Guaranteed
accuracy period
1 year
Operating
temperature
0 to 50°C (32 to 122°F)
Operating
humidity
Up to 40°C (104°F) 80%RH or less
40°C to 45°C (104 to 113°F) 60%RH or less
45°C to 50°C (113 to 122°F) 50%RH or less (non-condensing)
Storage
temperature and
humidity
-10°C to 50°C (14 to 122,°F)
80%RH or less (non-condensing)
Operating
environment
Indoors, Pollution degree 2, altitude up to 2000 m (6562-ft.)
Drop proof 1 m onto concrete surface
Power supply 5 VDC or LR6 alkaline battery × 2
Rated supply
voltage
Battery power 1.5 V DC × 2
AC adapter 5 V DC ±0.3 V
Maximum rated
power
0.5 VA
Continuous op-
erating time
FT3405: Approx. 30 hours
FT3406: Approx. 25 hours
*When using alkaline batteries with buzzer off.
Dimensions
(max.)
Approx. 71(W)×186(H) × 38(D)mm
(2.80"W × 7.32"H ×1.50"D)
Mass Approx. 230g (8.1 oz) (Including battery)
Dust resistance IP50 (EN60529)
Applicable
Standards
EMC :EN61326
Safety :EN61010
Accessory Instruction manual ...............................................................1
9211 Reflective Tape...........................................................1
L9094 Output Cord (FT3406 only).......................................1
C0202 Carrying Case..........................................................1
LR6 alkaline battery.............................................................2
Option Z5003 Contact Adapter
9032 Metal Contact Tip
9033 Rubber Contact Tip
9212 Peripheral Ring
Z1004 AC Adapter (FT3406 only)
L9094 Output Cord (FT3406 only)
9211 Reflective Tape
C0202 Carrying Case
