Preparing for Measurement
CAUTION
Attach the strap securely to the four ttings on the
instrument. If insecurely attached, the instrument may fall
and be damaged when carrying.
1
Attach the strap.
Slightly extend each of the four
double-loop split rings and pass
the ring through a lug-hole on
the instrument.
Secure the strap at
4 positions.
2
Insert the batteries. (p. 22)
3
Connect the test leads to the terminals.
EARTH terminal
Connect the black
test lead.
LINE terminal
Connect the red
test lead.
4
Attach each test pin or alligator clip to a lead.
Fully insert the test lead to the
test pin or alligator clip.
or
2 Preparing for Measurement
