Hioki IR4055 - Voltage Characteristics of Measurement Terminals

38
Insulation Resistance Measurement
Voltage Characteristics of Measurement Terminals
1200
1000
800
600
400
200
100
0
0 0.1 0.25 0.5 1 10 100 1000
∞
0.05 0.125
Resistance of measuring object [M
Ω
]
Rated 1000 V
Rated 500
V
Rated 250
V
Rated 125
V
Rated 50
V
Voltage generated [V]
HIOKI IR4057B961-00
