Ring/Network coupling
Redundanz L2P
Release
5.0
04/09
5.2
Preparing a Ring/Network coupling
73
5.2.4
Two-Switch coupling with control line
Figure 36:
Example of T
wo-Swit
ch coupling with control line
1: Backbone
2: Ring
3: Main line
4: Redundant line
5: Control line
IO
STAND-BY
STAND-BY
IO
RM
RM
34
5
1
2
72
74
