Installation MACH102
Release
06
09/2014
39
3 Technical data
General technical data
Dimensions
W × H × D
MACH102-... 17.64 in. × 1.73 in. × 12.21 in. (448 mm × 44 mm
× 310 mm) (without brackets)
Weight of devices MACH102-8TP
MACH102-8TP-R
MACH102-8TP-F
MACH102-8TP-FR
MACH102-24TP-F
MACH102-24TP-FR
7.94 lb (3.60 kg)
8.49 lb (3.85 kg)
7.94 lb (3.60 kg)
8.49 lb (3.85 kg)
8.49 lb (3.85 kg)
9.04 lb (4.10 kg)
Weight of
media modules
M1-8TP-RJ45
M1-8MM-SC
M1-8SM-SC
M1-8SFP
M1-8TP-RJ45 PoE
0.21 kg
0.21 kg
0.18 kg
0.13 kg
0.26 kg
Power supply
Basic device
Nominal voltage AC 100 V ... 240 V
Rated voltage range
AC
90 V ... 264 V
Rated frequency 50 Hz ... 60 Hz
Rated frequency range 47 Hz ... 63 Hz
Rated current range 0.4 A ... 0.2 A
Power supply
M1-8TP-RJ45 PoE
(for Type1 PD)
Rated voltage
Rated current
48 V DC, SELV (45 V DC ... 57 V DC)
2.5 A
Power supply
M1-8TP-RJ45 PoE
(for Type2 PD)
Rated voltage
Rated current
54 V DC, SELV (51 V DC ... 57 V DC)
2.5 A
Overload current
protection at input
Non-replaceable fuse
Activation current typ. <40 A at 265 V AC and cold start
Signal contact Switching current max. 1 A
Switching voltage max. 60 V DC or max. 30 V AC, SELV
Environment Storage temperature
(ambient air tempera-
ture)
Humidity
Air pressure (in opera-
tion)
-20 °C to +85 °C
10% to 95% (non-condensing)
Up to 2000 m (795 hPa), higher altitudes on
request
Operating
temperature
0 °C to +50 °C
Pollution degree 2
Protection classes Laser protection
Level of protection
Class 1 according to EN 60825-1 (2001)
IP20
