Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release
12
06/2018
37
The media module MSM50-Q6Q6Q6Q6... has 4 SFP slots for
1/2.5 Gbit/s F/O connections (connection via SFP transceivers).
Note: On the basic device MSP40/42, the media module slot 1 is coded
differently from the other slots. Only MSM50 media modules can be
installed on this media module slot.
1.4 Number of ports and connections
Depending on their varian, the basic devices offer you the following number
of slots for media modules and the following maximum amount of
connectable network segments:
The maximum data rate of the media modules depends on their slot on the
basic device. Some media modules only support data rates up to 10/
100 Mbit/s.
See “Device name and product code” on page 20.
Basic device Total
number
of slots
Number of
slots for 10/
100 Mbit/s
(FE)
Number of
slots for
1000 Mbit/s
(GE)
Max. number of
connectable 10/
100 Mbit/s
network
segments
Max. number of
connectable
1000 Mbit/s
network
segments
MSP30-0804...
MSP32-0804...
32 1 12 4
MSP30-1604...
MSP32-1604...
54 1 20 4
MSP30-2404...
MSP32-2404...
76 1 28 4
Table 26: Number of slots and maximum connectable network segments
Basic device Total
number of
slots
Number of
slots for 10/
100/
1000 Mbit/s
(GE)
Number of
slots for 10/
100/
1000 Mbit/s
(GE)
Max. number of
connectable 10/
100/1000 Mbit/s
network
segments
Max. number of
connectable
1000/2500 Mbit/s
network
segments
MSP40-0012...
MSP42-0012...
32 1 8 4
MSP40-0020...
MSP42-0020...
54 1 16 4
MSP40-0028...
MSP42-0028...
76 1 24 4
Table 27: Number of slots and maximum connectable network segments
