PowerMICE
Release 01 04/2014
Figure 7: Port assignment
1 - Port 1 (twisted pair)
2 - Port 2 (twisted pair)
3 - Port 3 (twisted pair)
4 - Port 4 (twisted pair)
1* - Port 1* (SFP slot, can be used as alternative to port 1)
2* - Port 2* (SFP slot, can be used as alternative to port 2)
3* - Port 3* (SFP slot, can be used as alternative to port 3)
4* - Port 4* (SFP slot, can be used as alternative to port 4)
5 - Representation of port numbers
6 - Bottom of device
1.1.3 MB-2T expansion module
The MB-2T expansion module allows you to add 2 slots for media modules
to the basic module.
Figure 8: MB-2T expansion module
1*
5
6
3*
2*
4*
6
1
2
3
4
