1.1.1 PowerMICE basic module MS4128
The basic module of the PowerMICE contains all the function units, such as:
switch function, management function, redundancy function, display control,
voltage connection, management connection, adjustable controls, slots for
media modules.
The basic module provides:
4 slots for 10/100 Mbit/s media modules
1 slot for 1 Gbit/s media modules
With the expansion module you add 2 more slots for 10/100 Mbit/s media
modules. With its 4-port media modules, the basic module allows you to
connect up to:
16 network segments or
24 network segments when using an expansion module
and additionally
4 Gigabit network segments when using a 4-port Gigabit media module.
Family Designed for:
PowerMICE larger numbers of ports
larger bandwidth requirement
Selectable via media modules:
Number of 100/1000 Mbit/s ports
