Hirschmann PowerMICE MM3-4FXM2

50
PowerMICE
Release 01 04/2014
Module Power
consump-
tion
Power output Operating
temperature
(ambient air
temperature)
Order
number
MM2 media modules:
MM2-4TX1 0.8 W 2.8 Btu (IT)/h 0 °C to +60 °C 943 722-101
MM2-4TX1-EEC 0.8 W 2.8 Btu (IT)/h -40 °C to +70 °C 943 722-051
MM2-4FXM3 7.0 W 23.9 Btu (IT)/h 0 °C to +60 °C 943 721-101
MM2-2FXM3/2TX1 3.4 W 11.6 Btu (IT)/h 0 °C to +60 °C 943 720-101
MM2-2FXM2 3.4 W 11.6 Btu (IT)/h 0 °C to +60 °C 943 718-101
MM2-2FXS2 3.4 W 11.6 Btu (IT)/h 0 °C to +60 °C 943 719-101
MM3 media modules:
MM3-4FLM4 5.0 W 17.1 Btu (IT)/h 0 °C to +60 °C 943 760-101
MM3-4TX5 0.8 W 2.8 Btu (IT)/h 0 °C to +60 °C 943 841-101
MM3-1FXM2/3TX1 2.2 W 7.5 Btu (IT)/h 0 °C to +60 °C 943 839-101
MM3-1FXM2/3TX1-EEC 2.2 W 7.5 Btu (IT)/h -40 °C to +70 °C 943 839-051
MM3-2FXM2/2TX1 3.4 W 11.6 Btu (IT)/h 0 °C to +60 °C 943 761-101
MM3-2FXM2/2TX1-EEC 3.4 W 11.6 Btu (IT)/h -40 °C to +70 °C 943 761-151
MM3-2FXM4/TX1 3.4 W 11.6 Btu (IT)/h 0 °C to +60 °C 943 837-101
MM3-4FXM2 7.0 W 23.9 Btu (IT)/h 0 °C to +60 °C 943 764-101
MM3-4FXM4 7.0 W 23.9 Btu (IT)/h 0 °C to +60 °C 943 835-101
MM3-1FXS2/3TX1 2.2 W 7.5 Btu (IT)/h 0 °C to +60 °C 943 838-101
MM3-2FXS2/2TX1 3.4 W 11.6 Btu (IT)/h 0 °C to +60 °C 943 762-101
MM3-4FXS2 7.0 W 23.9 Btu (IT)/h 0 °C to +60 °C 943 836-101
MM3-1FXL2/3TX1 3.4 W 11.6 Btu (IT)/h 0 °C to +60 °C 943 763-101
MM4 media modules:
MM4-4TX/SFP 9.0 W 30.8 Btu (IT)/h 0 °C to +60 °C 943 010-101
MM4-2TX/SFP 5.8 W 19.8 Btu (IT)/h 0 °C to +60 °C 943 622-101
Open variant media modules:
MM20-... 4 TX-/0 FX ports 0.8 W 2.8 Btu (IT)/h See table 19 See table 19
MM20-... 3 TX-/1 FX ports 2.3 W 7.9 Btu (IT)/h - “ - - “ -
MM20-... 2 TX-/2 FX ports 3.8 W 13.0 Btu (IT)/h - “ - - “ -
MM20-... 0 TX-/2 FX ports 3.8 W 13.0 Btu (IT)/h - “ - - “ -
MM20-... 1 TX-/3 FX ports 5.3 W 18.1 Btu (IT)/h - “ - - “ -
MM20-... 0 TX-/4 FX ports 6.8 W 23.2 Btu (IT)/h - “ - - “ -
MM20-A8A89999... 3.4 W 11.6 Btu (IT)/h - “ - - “ -
MM20-F4F4F4F4... 5.0 W 17.1 Btu (IT)/h - “ - - “ -
MM20-Z6Z6Z6Z6... 8.0 W 27.3 Btu (IT)/h - “ - - “ -
MM20-P9P9P9P9SAHH 8.0 W 27.3 Btu (IT)/h 0 °C to +60 °C - “ -
MM20-P9P9T1T1SAHH 5.2 W 17.8 Btu (IT)/h 0 °C to +60 °C - “ -
MM22-T1T1T1T1...
- internal operating voltage
- external PoE voltage
- no PD
- 4 x Class0-PD
0.8 W
1.3 W
2 W + PDs
2.8 Btu (IT)/h
4.3 Btu (IT)/h
6.9 Btu (IT)/h
- “ - - “ -
MM23-T1T1T1T1... 4.5 W 15.4 Btu (IT)/h 0 °C to +60 °C - “ -
MM23-M2M2T1T1... 6.0 W 20.5 Btu (IT)/h 0 °C to +60 °C - “ -
Table 18: Other modules: power, temperature, order numbers
