Hirschmann RS20 Programming Manual

Rapid Spanning Tree
Redundanz L2P
Release 5.0 04/09
6.7 Combination of RSTP and MRP
109
Prerequisities for further configuration:
X You have configured the MRP settings for the devices in accordance with
the above table.
Figure 56: Application example for the combination of RSTP and MRP
1: MRP-Ring
2: RSTP-Ring
3: Redundant RSTP connection
RM: Ring Manager
RM
S1
S3
S2
S4
3
1.1 1.11.2
1.3
1.3
1.2
1.1
1.2
1.1
1.2
1
2

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
