Ring Redundancy

3.1

Example of HIPER-Ring

Redundanz L2P

Release

5.0

04/09

3.1.1 Setting up and configuring the HIPER-Ring

 Set up the network to meet your requirements.

 You configure all 6 ports so that the transmission speed and the duplex

settings of the lines correspond to the following table:

Bit rate 100 Mbit/s 1000 Mbit/s

Autonegotiation

(automatic configuration)

off on

Port on on

Duplex Full –

Table 2: Port settings for ring ports

 Select the Redundancy:Ring Redundancy dialog.

 Under “Version”, select HIPER-Ring.

 Define the desired ring ports 1 and 2 by making the corresponding

entries in the module and port fields. If it is not possible to enter a

module, then there is only one module in the device that is taken

over as a default.

Display in “Operation” field:

– active: This port is switched on and has a link.

– inactive: This port is switched off or it has no link.
