Hirschmann RS20 Programming Manual

Sub-Ring (RSR20, RSR30, MACH1000)
44
Redundanz L2P
Release 5.0 04/09
Note: Sub-Rings use MRP. You can couple Sub-Rings to existing basis rings
with the HIPER-Ring protocol, the Fast HIPER-Ring protocol and MRP.
When you couple a Sub-Ring to a basis ring under MRP, you configure both
rings in different VLANs. You configure
X either the Sub-Ring ports of the Sub-Ring Manager and the devices of the
Sub-Ring in a separate VLAN. Here multiple Sub-Rings can use the same
VLAN.
X or the devices of the basis ring, including the basis ring ports of the Sub-
Ring Manager, in a separate VLAN. This reduces the configuration work
when you are coupling multiple Sub-Rings to a basis ring.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
