Ring/Network coupling

5.2

Preparing a Ring/Network coupling

Redundanz L2P

Release

5.0

04/09

Note: For redundancy security reasons, the combination of Rapid Spanning

Tree and Ring/Network Coupling is not possible.

Depending on the STAND-BY DIP switch position, the dialog displays

those configurations that are not possible in gray. If you want to select

one of these grayed-out configurations, you put the STAND-BY DIP

switch on the Switch into the other position.

One-Switch coupling

Assign the device the DIP switch setting “STAND-BY”, or use the soft-

ware configuration to assign the redundancy function to it.

Two-Switch coupling

Assign the device in the redundant line the DIP switch setting “STAND-

BY”, or use the software configuration to assign the redundancy func-

tion to it.
