RS20/RS30...U
Release
01
06/2012
17
Item Characteristic Ident. Ident.2
a)
a. For device variants with two uplink ports you use the “Ident.” column for items 10+11 and for
items 12+13.
For device variants with three uplink ports you use the “Ident.2” column for items 10+11 and
the “Ident.” column for items 12+13.
For device variants with four uplink ports you use the “Ident.2” column for items 10+11 and
for items 12+13.
Property
1 to 4 Product RS20 Rail Switch without gigabit ports
RS30 Rail Switch with gigabit ports
5 - (hyphen) -
6 to 7 Number of 10/100 08 8 * 10/100 Mbit Ethernet
Mbit ports 09 9 * 10/100 Mbit Ethernet
16 16 * 10/100 Mbit Ethernet
17 17 * 10/100 Mbit Ethernet
24 24 * 10/100 Mbit Ethernet
25 25 * 10/100 Mbit Ethernet
8 and 9 Number of 1000 00 0 * 1000 Mbit Ethernet
Mbit ports 02 2 * 1000 Mbit Ethernet
10 and 11
a)
Uplink port(s) T1 Twisted pair T(X), RJ45
1 port (Ident.
column)
M2 MM
b)
b. For RS20-0900...U, RS20-1700...U, RS20-2500...U
Multimode FX, DSC, 100 Mbit
or alternatively M4 NN
b)
Multimode FX, ST, 100 Mbit
2 ports S2 VV
b)
Singlemode FX, DSC, 100 Mbit
(Ident.2 column) S4 UU
b)
Singlemode FX, ST, 100 Mbit
L2 LL
b)
Singlemode Longhaul, DSC, 100 Mbit
O6 OO
c)
c. In connection with “2nd uplink port” “ZZ” and “1st uplink port” “OO”.
SFP slot, 1000 Mbit
Z6 ZZ
c)
SFP slot, 100 Mbit
12 and 13
a)
See items 10 and
11
14 Temperature range S Standard 0 °C to +60 °C
T Extended -40 °C to +70 °C
d)
d. Not when using GG or G2 transceivers.
E Extended -40 °C to +70 °C, conformal
coating
d)
15 Voltage range D 9.6 VDC to 60 VDC or 18 VAC to 30 VAC
16 Certification A CE, UL508, ISA 12.12.01 (UL1604)
H
e)
e. Without railway certification EN50155 (Train).
CE, UL508, ISA 12.12.01 (UL1604), GL,
Railway (along track), Sub Station
B
e)
CE, UL508, ISA 12.12.01 (UL1604), GL,
Railway (along track), Sub Station,
Hazardous Location (ATEX)
17 Software variant U Unmanaged
Table 2: Combination options for the device variants RS20...U/RS30...U
