1.1.3 Number of ports and media for RS30...U
Figure 5: Device variants with 2 * 1000 Mbit/s ports and 8 * 10/100 Mbit/s ports
(RS30-0802...U)

1 – plug-in terminal block, 6-pin 
2 – LED display elements 
3 – 2-pin DIP switch 
4 – ports in compliance with 10/100BASE-T(X) (RJ45 connections) 
5 – port 1 + port 2, free choice of connections: 
T1: Twisted-pair T(X), RJ45, 10/100/1000 Mbit/s 
O6: SX/LX, SFP slot, 1000 Mbit/s
RS30-0802T1T1...D...U
RS30
LA learn
+24V(P1) 0V 0V
FAULT
+24V(P2)
SW2
3
5
7
9
4
6
8
10
P FAULT
ON
DA
2
LS
DA
1
LS
RS30-0802O6T1...D...U
RS30
LA learn
+24V(P1) 0V 0V
FAULT
+24V(P2)
SW2
LS DA
1
P FAULT
ON
DA
2
LS
3
5
7
9
4
6
8
10
RS30-0802O6O6...D...U
RS30
LA learn
+24V(P1) 0V 0V
FAULT
+24V(P2)
SW2
P FAULT
ON
LS DA
1
LS DA
2
3
5
7
9
4
6
8
10
4
5
5
1
2
3
