1.1.2 Number of ports and media for RS20...U
Figure 1: Device variants with 8 * 10/100 Mbit/s ports (RS20-0800...U) 
1 – plug-in terminal block, 6-pin 
2 – LED display elements 
3 – 2-pin DIP switch 
4 – ports in compliance with 10/100BASE-T(X) (RJ45 connections) 
5 – port 1 + port 2, free choice of connections: 
T1: Twisted-pair T(X), RJ45, 10/100 Mbit/s 
M2: Multimode FX, DSC, 100 Mbit/s 
M4: Multimode FX, ST, 100 Mbit/s 
S2: Singlemode FX, DSC, 100 Mbit/s 
S4: Singlemode FX, ST, 100 Mbit/s 
L2: Singlemode Longhaul FX, DSC, 100 Mbit/s 
G2: Singlemode Longhaul+ FX, DSC, 100 Mbit/s, 200 km
RS20
LS DA
LA learn
+24V(P1) 0V 0V
FAULT
+24V(P2)
SW2
2
LS DA
1
3
5
7
4
6
8
P FAULT
ON
RS20-0800M2M2...D...U
RS20-0800M2T1...D...U
RS20
LA learn
+24V(P1) 0V 0V
FAULT
+24V(P2)
SW2
LS DA
1
3
5
7
4
6
8
P FAULT
ON
DA
2
LS
RS20
LA learn
+24V(P1) 0V 0V
FAULT
+24V(P2)
SW2
1
3
5
7
2
4
6
8
P FAULT
ON
RS20-0800T1T1...D...U
4
5
5
1
2
3
