Hirschmann RS30-...U Series - Disassembly

RS20/RS30...U
Release 01 06/2012
33
2.4 Disassembly
 Removing the device from the DIN rail
 To take the device off the DIN rail, insert a screwdriver horizontally
under the housing into the locking slide, pull it (without tipping the
screwdriver) downwards and lift the device upwards.
 Disassembling the SFP modules
 Pull the module out of the socket by means of the opened lock.
 Close the module with the protective cap.
