38
RS20/RS30...U
Release
01
06/2012
Power consumption/power output
Scope of delivery
Order numbers/product description
See table on page 16 “Combination options for RS20/30-...U”.
Device name Device model Maximum
power
consumption
Power output
2 uplink ports:
RS20-0800... 2xTX port 5.3 W 18.1 Btu (IT)/h
RS20-0800... 1xFX port, 1xTX port 6.5 W 22.2 Btu (IT)/h
RS20-0800... 2xFX port 7.3 W 26.3 Btu (IT)/h
RS20-1600... 2xTX port 9.4 W 32.1 Btu (IT)/h
RS20-1600... 1xFX port, 1xTX port 10.6 W 36.2 Btu (IT)/h
RS20-1600... 2xFX port 11.8 W 40.3 Btu (IT)/h
RS20-2400-... 2xTX port 12.1 W 41.3 Btu (IT)/h
RS20-2400-... 1xFX port, 1xTX port 13.3 W 45.4 Btu (IT)/h
RS20-2400-... 2xFX port 15.5 W 52.9 Btu (IT)/h
RS30-0802-... 2xTX port 8.9 W 30.4 Btu (IT)/h
RS30-0802-... 1xFX port, 1xTX port 8.6 W 29.4 Btu (IT)/h
RS30-0802-... 2xFX port 8.3 W 28.4 Btu (IT)/h
RS30-1602-... 2xTX port 13.0 W 44.4 Btu (IT)/h
RS30-1602-... 1xFX port, 1xTX port 12.7 W 43.4 Btu (IT)/h
RS30-1602-... 2xFX port 12.4 W 42.4 Btu (IT)/h
RS30-2402-... 2xTX port 15.7 W 53.6 Btu (IT)/h
RS30-2402-... 1xFX port, 1xTX port 15.4 W 52.6 Btu (IT)/h
RS30-2402-... 2xFX port 15.1 W 51.6 Btu (IT)/h
3 uplink ports:
RS20-0900-... 3xFX port 9.6 W 32.8 Btu (IT)/h
RS20-1700-... 3xFX port 13.7 W 46.7 Btu (IT)/h
RS20-2500-... 3xFX port 16.4 W 56.0 Btu (IT)/h
4 uplink ports:
RS30-0802-... 4xFX port 12.7 W 43.3 Btu (IT)/h
RS30-1602-... 4xFX port 16.8 W 57.3 Btu (IT)/h
RS30-2402-... 4xFX port 19.5 W 66.5 Btu (IT)/h
Table 12: Power consumption/power output RS20-...U/RS30-...U
Device Scope of delivery
RS20-...U, RS30-...U Device
Terminal block for supply voltage and signal contact
Installation user manual and CD-ROM
