Installation RSP 20/25/30/35
Release
15
12/2017
Ground the device via the ground screw.
For every supply voltage to be connected, perform the following steps:
Remove the power connector from the device.
Connect the protective conductor according to the pin assignment on the
device with the clamp.
Connect the wires according to the pin assignment on the device with the
clamps.
Fasten the wires connected by tightening the terminal screws.
You find the prescribed tightening torque in chapter:
“General technical data” on page 49
With a non-redundant supply of the supply voltage, the device reports the
loss of a supply voltage. You can prevent this message by changing the
configuration in the Management.
WARNING
ELECTRIC SHOCK
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
