Installation RSP 20/25/30/35
Release
15
12/2017
49
8 Technical data
8.1 General technical data
Dimensions
W × H × D
RSP 20/25/30/35 See “Dimension drawings” on page 53.
Weight RSP 20/25/30/35-.......TT-S...... approx. 2.65 lb (1.2 kg)
RSP 20/25/30/35-.......TT-T......
RSP 20/25/30/35-.......TT-E......
approx. 3.31 lb (1.5 kg)
RSP 20/25/30/35-.......ZT-S...... approx. 1.3 kg
RSP 20/25/30/35-.......ZT-T......
RSP 20/25/30/35-.......ZT-E......
approx. 1.6 kg
Supply voltage
with the
characteristic
value CC
See “Requirements for connecting electrical wires” on page 6.
Rated voltage DC 24 V DC ... 48 V DC
Voltage range DC including
maximum tolerances
18 V DC ... 60 V DC
Connection type 2-pin terminal block
Tightening torque 4.5 lb-in
(0.51 Nm)
Power loss buffer > 10 ms at 20.4 V DC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse for each voltage
input
Nominal rating:
Characteristic:
2A
slow blow
Peak inrush current < 4 A
Supply voltage
with characteristic
value TT
See “Requirements for connecting electrical wires” on page 6.
Rated voltage DC 12 V DC ... 24 V DC
Voltage range DC including
maximum tolerances
10.2 V DC ... 32 V DC
Connection type 2-pin terminal block
Tightening torque 4.5 lb-in
(0.51 Nm)
Power loss buffer > 10 ms at 10.2 V DC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse for each voltage
input
At rated voltage DC 12 V DC
Nominal rating:
Characteristic:
5A
slow blow
Back-up fuse for each voltage
input
At rated voltage DC 24 V DC
Nominal rating:
Characteristic:
4A
slow blow
Peak inrush current < 14 A
