Hirschmann RSPE 30 User Manual

Installation RSPE 30/32/35/37
Release 12 10/2015
29
1.6.2 Media module status
 Device variants RSPE 30 and RSPE 35
1 LED is located on the upper part of the media module.
This LED provides information on the supply voltage status of the media
module.
 Device variants RSPE 32 and RSPE 37
2 LEDs are located on the upper part of the media module.
These LEDs combined provide information on the supply voltage status
and the PoE status of the media module.
LED Display Color Activity Meaning
Power Supply voltage — None Media module is inoperative
Green Lights up Supply voltage is on
LED Display Color Activity Meaning
Power Supply voltage — None Media module is inoperative
Green Lights up Voltage supply to the media module is on
Voltage supply to the PoE port is on
Yellow Lights up PoE voltage is missing or is too low
Power
Power
P
