Hirschmann RSPE 30 User Manual

Installation RSPE 30/32/35/37
Release 12 10/2015
53
8 Technical data
 General technical data
Dimensions
W × H × D
RSPE 30/32/35/37 See “Dimension drawings” on page 56.
Weight Devices with operating
temperature characteristic
value S (standard):
4.6 lb (2.2 kg)
Devices with operating
temperature characteristic
value E and T (extended):
5.5 lb (2.5 kg)
Supply voltage
with the
characteristic
value CC
See “Requirements for connecting electrical wires” on page 6.
Nominal voltage DC 24 V ... 48 V
Voltage range DC incl.
maximum tolerances
18 V ... 60 V
Rated current DC RSPE30/32 0.6 A ... 1.3 A
RSPE35/37 0.7 A ... 1.4 A
Connection type 2-pin terminal block
Power loss buffer > 10 ms at 20.4 V DC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse for each voltage
input
Nominal
rating:
Characteristic:
1A
slow blow
Peak inrush current < 4 A
Supply voltage
with the
characteristic
value K9
and KK
See “Requirements for connecting electrical wires” on page 6.
Nominal voltage AC 110 V ... 230 V, 50 Hz ... 60 Hz
Voltage range AC incl.
maximum tolerances
88 V ... 265 V, 47 Hz ... 63 Hz
Nominal voltage DC 60 V ... 250 V
Voltage range DC incl.
maximum tolerances
48 V ... 320 V
Rated current AC RSPE30/32 0.2 A ... 0.3 A
RSPE35/37
Rated current DC RSPE30/32 0.1 A ... 0.3 A
RSPE35/37 0.2 A ... 0.6 A
Connection type 3-pin terminal block
Power loss buffer > 10 ms at 98 V AC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
1 A ... 20 A
slow blow
Peak inrush current < 3.5 A
