62
Installation RSPE 30/32/35/37
Release
12
10/2015
Power consumption/power output, order numbers
The order numbers correspond to the product codes of the devices.
See “Device name and product code” on page 17.
Scope of delivery
Device name Maximum
power
consumption
a
a. You can find the total power consumption specifications for basic modules that are to be
installed in the “User Manual Installation RSPM”.
Power output
RSPE
30
16 W 55 BTU (IT)/h
RSPE
32
including 124 W PoE output power 151 W 92 BTU (IT)/h
RSPE
35
18 W 61 BTU (IT)/h
RSPE
37
including 124 W PoE output power 153 W 98 BTU (IT)/h
RSPM20-4Z64Z6... 9 W 31 BTU (IT)/h
RSPM20-4T14T1... 2 W 7 BTU (IT)/h
RSPM20-4T14Z6... 5 W 17 BTU (IT)/h
RSPM22-4T14T1... including PoE output power 2 W 7 BTU (IT)/h
RSPM22-4T14Z6... including PoE output power 5 W 17 BTU (IT)/h
Number Article
1× Device
1 × 2-pin terminal block for signal contact
1 × 3-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with the characteristic value K9)
2 × 3-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with the characteristic value KK)
2 × 2-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with the characteristic value CC
or PP)
1 × Installation user manual
1 × CD/DVD with manual
