Installation RSPE 30/32/35/37
Release
12
10/2015
31
Fast Ethernet port
LED Display Color Activity Meaning
L/D Link status — None Device detects an invalid or missing
link
Green Lights up Device detects a valid link
Flashes 1 time a period Port is switched to stand-by
Flashes 3 times a period Port is switched off
Yellow Lights up Device detects a non-supported SFP
transceiver or a non-supported data
rate
Flashing Device is transmitting and/or receiving
data
Flashes 1 time a period Device detects at least one
unauthorized MAC address (Port
Security Violation)
PoE PoE status — None RSPE 30, RSPE 35:
LED is without any function
RSPE 32, RSPE 37:
No powered device connected
Green Lights up Power device is supplied with PoE
voltage
Yellow Flashes 1 time a period Output budget has been exceeded
Device has detected a connected
powered device
Flashes 3 times a period PoE administrator status deactivated
FX
TX
PoE
L/D
L/D
