Installation RSPL 20/30
Release
04
02/2013
23
1.7 Display elements
After the operating voltage is set up, the software starts and initializes itself.
Afterwards, the device performs a self-test. During this process, various
LEDs light up.
1.7.1 Device state
These LEDs provide information about conditions which affect the operation
of the whole device.
LED Display Color Activity Meaning
Power Power supply — None The supply voltage is too low.
Yellow Lights up Device variants with redundant voltage
supply:
The supply voltages 1 or 2 are on.
flashes 4 times
a period
Software update is running. Maintain the
voltage supply.
Green Lights up Device variants with redundant voltage
supply:
The supply voltages 1 and 2 are on.
Device variants with simple voltage
supply:
The supply voltage is on.
Status Device Status — None Device is starting and/or is not ready for
operation.
Green Lights up Device is ready for operation.
Characteristics can be configured.
Red Lights up Device is ready for operation.
The Device detects and displays the
system monitoring results when at least
one unussual event occurs.
Flashes 1 time
a period
The boot parameters used when the
device has been started differ from the
boot parameters saved.
Start the device again.
flashes 4 times
a period
Device has detected a multiple IP
address.
RM Redundancy
Manager
— None No redundancy configured
Green Lights up Redundancy exists
Flashes 1 time
a period
Device is reporting an incorrect
configuration of the RM function.
Yellow Lights up No redundancy exists
ACA Storage medium
ACA31
— None The storage medium ACA is not inserted.
Green Lights up The storage medium ACA is inserted.
Flashes 3
times a period
The device allows read and write access.
Yellow Lights up The storage medium ACA is out of order.
Status
RM
ACA
Power
