Installation RSPL 20/30
Release 04 02/2013
7 Technical data
 General technical data
Dimensions
W × H × D
RSPL 20/30 See “Dimension drawings” on page 42.
Weight RSPL-20-... approx. 1.0 kg
RSPL-30-... approx. 1.2 kg
Power supply
Power supply
type CC
Nominal voltage DC 24 V ... 48 V Class 2
Voltage range DC incl.
maximum tolerances
18 V ... 60 V Class 2
Connection type 2-pin terminal block
Power failure bypass > 10 ms at 20.4 V DC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse for each voltage
input
Nominal rating:
Characteristic:
1A
slow blow
Peak inrush current < 4 A
Power supply
Power supply
type M9
Nominal voltage AC 110 V ... 230 V, 50 Hz ... 60 Hz
Voltage range AC incl.
maximum tolerances
88 V ... 265 V, 47 Hz ... 63 Hz
Nominal voltage DC 110 V ... 250 V
Voltage range DC incl.
maximum tolerances
88 V ... 320 V
Connection type 3-pin terminal block
Power failure bypass > 10 ms at 98 V AC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
1 A ... 20 A
slow blow
Peak inrush current < 3.5 A
Climatic
conditions
during operation
Ambient temperature Devices with operating temperature type S
(standard):
+32 °F ... +140 °F (0 °C ... +60 °C)
a
Devices with operating temperature type E
and type T (extended):
−40 °C ... +70 °C
b
−40 °C ... +85 °C for 16 hours (tested in
accordance with IEC 60068-2-2)
c
Maximum inner temperature of
device (guideline)
Devices with operating temperature type S
(standard):
83 °C
Devices with operating temperature type E
and type T (extended):
93 °C
Humidity 5 % ... 95 %
(non-condensing)
Air pressure minimum 700 hPa (+3000 m)
maximum 1060 hPa (−400 m)
