46
Installation RSPL 20/30
Release
04
02/2013
Damped vibration - AC/DC supply connection
EN 61000-4-12
IEEE C37.90.1
line/ground — — 2.5 kV
EN 61000-4-12
IEEE C37.90.1
line/line — — 1 kV
Damped vibration - data line
EN 61000-4-12
IEEE C37.90.1
line/ground — — 2.5 kV
EN 61000-4-12 line/line — — 1 kV
Impulse-shaped magnetic fields
EN 61000-4-9 — 300 A/m 300 A/m
a. EN 61131-2, CE, FCC – applies to all devices
b. EN 50121-4 – applies to devices with the certification codes VT, T9, TY
c. EN 61850-3, IEEE 1613 – applies to devices with the certification codes V9, VY, VT
EMC interference
immunity
Standard
applications
a
Railway
applications
(trackside)
b
Sub-station
applications
c
