Installation RSPL 20/30
Release 04 02/2013
49
 Power consumption/power output, order numbers
The order numbers correspond to the product codes of the devices.
See “Device name and product code” on page 14.
 Scope of delivery
 Accessories
Note: Please note that products recommended as accessories may have
characteristics that do not fully match those of the corresponding product.
This may limit their possible usage in the overall system.
Device name Maximum
power
consumption
Power output
RSPL20-08002Z6TT........ 8 W 27 BTU (IT)/h
RSPL20-08002Z6YT........ 10 W 34 BTU (IT)/h
RSPL30-08022O7YT........ 14 W 47 BTU (IT)/h
RSPL30-08022O7ZT........ 16 W 55 BTU (IT)/h
Number Article
1× Device
1 × 2-pin terminal block for signal contact
1 × 3-pin terminal block for supply voltage
(Only for device variants with operating voltage type M9)
2 × 2-pin terminal block for supply voltage
(for device variants with operating voltage type CC only)
1 × Installation user manual
1 × CD/DVD with manual
Name Order number
Terminal cable 943 301-001
AutoConfiguration Adapter ACA 31 942 074-001
For device variants with operating voltage type M9:
3-pin terminal block (50 pieces) for supply voltage
943 845-008
For device variants with operating voltage type CC:
2-pin terminal block (50 pieces) for supply voltage
943 845-009
2-pin terminal block (50 pieces) for signal contact 943 845-010
Power Cord 942 000-001
Network management software Industrial HiVision 943 156-xxx
Gigabit Ethernet SFP transceiver Order number
M-SFP-SX/LC 943 014-001
M-SFP-SX/LC EEC 943 896-001
M-SFP-MX/LC 942 035-001
M-SFP-LX/LC 943 015-001
M-SFP-LX/LC EEC 943 897-001
M-SFP-LX+/LC 942 023-001
M-SFP-LX+/ LC EEC 942 024-001
