NOTE!
The surface to which the protective film is fitted must be clean and dry.
WARNING!
Countertop might be damaged by moist if protective film is not properly installed.
3. Prepare water supply, drainage and electrical
connections
Slide the dishwasher near desired install location.
• If connect to power via plug: Pull the drain, plug cord and supply hoses through the opening as
the dishwasher is slid into place.
• If connect to power via junction box: Prepare the necessary power supply cord for connection
and paste it on the floor where the dishwasher will be installed (to facilitate the step 6 of connecting
the supply cord into the junction box). Then, pull the drain and supply hoses through the opening
as the dishwasher is slid into place.
Inches (mm)
Direct wire location
Check that the hoses have no kinks or sharp bends, and check that there is nothing that can damage
the hoses.
4. Adjust the height and slide the dishwasher into place
1. Start by measuring the height from the floor to the bottom edge of the countertop.
2. Measure the height from the floor to the top edge of the dishwasher.
3. Lean the dishwasher forward a little and adjust the rear foot with the screw at the front of the
dishwasher. Turn clockwise to lower or counterclockwise to raise.
32
