5.3 Wall Mounting the Surround
1. The (R/L) Surround Speakers can be fixed
to the wall using the included wall mount
package.
2. Note: Before installing the wall bracket, you
need to connect the power/speaker cables of
the (R/L) Surround Speakers.
1
2
6. Connections
6.1 Use the HDMI eARC/ARC Socket
The eARC/ARC (Enhance Audio Return Channel)
function allows you to send audio from your ARC-
compliant TV to your soundbar through a single
HDMI connection. To enjoy the ARC function,
please ensure your TV is both HDMI-CEC and ARC
compliant and set up accordingly. When correctly
set up, you can use your TV remote control to
adjust the volume output (VOL
+
/
−
and MUTE)
of the soundbar.
• Connect the HDMI cable from soundbar
HDMI (TV eARC/ARC
)
socket to the HDMI
eARC/ARC socket on your ARC compliant TV.
Then press the remote control to select HDMI
eARC/ARC.
Tips:
• Your TV must support the HDMI-CEC and
ARC function. HDMI-CEC and ARC must be
set to On.
• The setting method of HDMI-CEC and ARC
may differ depending on the TV. For details
about eARC/ARC function, please refer to the
owner’s manual.
• Only HDMI 1.4 or higher version cable can
support the ARC function.
Use with Roku TV
• If you have a Roku TV™, simply plug in the
HDMI cable to the eARC/ARC ports and follow
the Roku TV Ready™ on-screen instructions.
Use the Hisense EzPlay Function
For Hisense EzPlay, when the Soundbar connects
with a Hisense TV via HDMI eARC/ARC, there will be
a Soundbar Setting menu on the TV, and you can
control this menu via your TV remote to control
most of the Soundbar features.
TV menu example (different models may have
different menus) :
3.5x50mm
eARC/ARC
eARC/ARC
