CAUTION:
To avoid personal injury:
HOW TO OPEN THE HOOD AND TILT
THE SEAT
CAUTION
To avoid personal injury from contact with
moving parts:
Never open operator’s seat while the
engine is running.
Depress the hood with your
other hand
while unlocking
the hood.
■Hood
To open the hood, turn the switch to release
the latch and lift the hood off.
[1]Latch
[2] Hood
[3] “Open”from “[a]” direction of rotation
“Close”from “[b]” direction of rotation
■Operator’s Seat
To open the seat, raise the seat to the
forward position.
USE HANDLE (A) TO UNLOCK, THEN SLIDE
SEAT TO THE DESIRED POSITION (B) AND
RELEASE HANDLE (A).
JACK POSITIONING
WARNING
To avoid personal injury, death or vehicle
damage:
Do not work under the vehicle unless it
is secured by safe stands or suitable
blocking.
■Front End
Jack stand at the front bumper only.
[1] Jack [2] Front bumper
