Connections
Speaker Connections
Connect the speaker cables at the back of the speakers to the SPEAKER OUT (L/R) Sockets
at the rear of the unit.
Connecting Control Cable
Connect the control cable between the CD player and the amplier.
Rear of the Amplier
Rear of the Amplier
Rear of the CD Player
Control Cable
AC~
L
R
L
R
DAB
AUX
CABLE
SPEAKER OUT
CABLE
