Connecting the Aerial
Connect one end of the aerial cable (included) to the DAB socket at the rear of the unit.
Then position the aerial to obtain optimum reception.
AC~
L
R
L
R
DAB
AUX
CABLE
SPEAKER OUT
Rear of the Amplier
Connecting to the Mains Supply
• This unit is designed to operate with an AC 230V ~50Hz power supply.
• Connecting the unit to any other power source may cause damage to the unit. Unwind
the mains cable to its full length. Connect the mains plug to a mains socket. Make sure
the mains plug is fully inserted into the mains socket. The unit is now connected and
ready to use.
• To switch the unit o completely, remove the mains plug from the mains socket.
To the mains
socket
Ensure all connections are connected before connecting to the mains power socket.
