24
English
8. Lubrication
Lubricate the following sliding surfaces once a month to keep the power tool in good operating condition
for a long time (see Fig. 1 and Fig. 2). Use of machine oil is recommended.
Oil supply points:
*Rotary portion of hinge
*Rotary portion of vise assembly
9. Cleaning
Periodically remove chips, dust and other waste material from the surface of the power tool, especially
from the inside of the lower guard with a damp, soapy cloth. To avoid a malfunction of the motor,
protect it from contact with oil or water.
(For Model C12LCH/C12FCH)
If the laser line becomes invisible due to chips and the like adhered onto the window of the laser
marker's light-emitting section, wipe and clean the window with a dry cloth or a soft cloth moistened
with soapy water, etc.
10.Service parts list
A: Item No.
B: Code No.
C: No. Used
D: Remarks
CAUTION: Repair, modification and inspection of Hitachi Power Tools must be carried out by a Hitachi
Authorized Service Center.
This Parts List will be helpful if presented with the tool to the Hitachi Authorized Service
Center when requesting repair or other maintenance. In the operation and maintenance
of power tools, the safety regulations and standards prescribed in each country must be
observed.
MODIFICATIONS:
Hitachi Power Tools are constantly being improved and modified to incorporate the latest technological
advancements.
Accordingly, some parts (i.e. code numbers and/or design) may be changed without prior notice.
SERVICE AND REPAIRS
All quality power tools will eventually require servicing or replacement of parts because of wear from
normal use. To assure that only authorized replacement parts will be used and that the double insulation
system will be protected, all service (other than routine maintenance) must be performed by an AUTHORIZED
HITACHI POWER TOOL REPAIR CENTER ONLY.
