- 29 -
GENERAL CHARACTERISTICS
Power supply for set-top box: 12 V DC 2Amp
Preffered DC Adaptor: 220 - 240 V AC, 50-60Hz
Input Frequency 470Mhz-862Mhz
Frequency Band UHF
Maximum Power consumption 17,5 W
Standby Power Consumption 0,5 W
Operating temperature 5ºC to +40ºC
Storage temperature -15ºC to +55ºC
Humidity 25 to 75 % rel
Physical dimensions 231x137x43mm
Weight 0,9kg
HARDWARE CONFIGURATION
Main Processor BCM7230
Flash Memory 64 MB
DDRRAM 512 MB
DIGITAL CAPABILITIES
Transmission Standards MPEG2, MPEG4 HD DVB-T-2
Frequency Band UHF
DEMODULATION
COFDM with 2K/8K FFT mode.
FEC for all DVB Modes.(Automatically found)
16QAM, 64QAM, 256QAM with 1k, 2k, 4k, 8k, 16k, 32k FFT mode
VIDEO
ALL MPEG-4 (part 10) MP@ML Video Decoder
Aspect Ratio 4:3, 16:9 with pan vector
RGB analogue outputs. BW ≥ 5MHz at 0.5 to 5 MHz sweep signal
CVBS analogue output.
Proles
MPEG-4 H.264/AVC HP@L 4.0, MP@L 4.0 (HD)
- H.264/AVC MP@L 3 .2, HP@L 3 .2 (SD)
- MPEG-2 MP@HL, MP@ML (SD)
AUDIO
MPEG1 Layer 1 and 2
Sampling frequencies supported 32 kHz, 44.1 kHz or 48 kHz.
Output can be programmed as STEREO, LEFT only or RIGHT only (on both outputs). This is useful for dual
mono channels in order to select the correct sound track, which is stored for every channel.
Wide dynamic range 16-bit resolution
For any help concerning set up and use of your STB please call the Customer Helpline: 0845 604 0105
