Hitachi L100 Series Quick Reference Guide

1
Caution: Be sure to read the L100 Inverter Manual and
follow its Cautions and Warnings for the initial product
installation. This Quick Reference Guide is intended for
reference use by experienced users in servicing existing
installations.
Power Circuit Terminals
–002NFE/NFU, –004NFE/NFU, –005NFE
Jumper
(/) +1 + –
L1 L2 N/L3 U/T1 V/T2 W/T3
Chassis
Ground
–007 to 022NFE/NFU, –037LFU, 004 to 040HFE/HFU
Jumper
(/) +1 + –
L1 L2 N/L3 U/T1 V/T2 W/T3
Chassis
Ground
–055LFU, –075LFU, 055HFE/HFU, 075HFE/HFU
Jumper
(/) +1 + –
L1 L2 N/L3 U/T1 V/T2 W/T3
Chassis
Ground
