Page #4 background imageLoading...
Page #4 background image
3
O Analog input, voltage 0 to 9.6 VDC range, 10VDC
nominal, 12VDC max., input
impedance 10 k
H +10V analog reference 10VDC nominal, 10 mA
max.
AL0 Relay common contact
Contact rating
Max resistive load = 250VAC,
2.5A; 30VDC 3A;
Max inductive load = 250VAC,
0.2A; 30VDC 0.7A
Minimum load = 5VDC 100mA,
100VAC, 10mA
AL1 Relay contact,
normally closed
during RUN
AL2 Relay contact,
normally open during
RUN
Termina l
Name
Description Ratings and Notes
