Hitachi L300P Series Quick Reference Guide

29
“P” Group: Expansion Card Functions
Func.
Code
Name / Description
Default
Val ue
–FE2/–FU2/
–FR
Set
Val ue
P001 Operation mode on expansion card #1 error
• 00 Trip (stop motor)
• 01 Continuous operation
00
P002 Operation mode on expansion card #2 error
• 00 Trip (stop motor)
• 01 Continuous operation
00
P044 DeviceNet comm watchdog timer 1.00
P045 Inverter action on DeviceNet comm error
•00Trip
• 01 Decelerate and trip
• 02 Hold last speed
• 03 Free run stop
• 04 Decelerate and stop
01
P046 DeviceNet polled I/O: Output instance number 21
P047 DeviceNet polled I/O: Input instance number 71
P048 Inverter action on DeviceNet idle mode
•00Trip
• 01 Decelerate and trip
• 02 Hold last speed
• 03 Free run stop
• 04 Decelerate and stop
01
P049 DeviceNet motor poles setting for RPM 0
P050 • Output frequency on analog reference signal
loss (–xFE2/–xFU2 models only)
• 00 Output freq. forced to 0 Hz; 500ms wait to
recover
• 01 Output freq. forced to 0 Hz; no wait to
recover
• 02 Output freq. forced to max. freq. A004
• 03 Output freq. forced to A020/A220
00 / 00 / —
