28
“H” Group: Motor Constants Functions
C085 Thermistor input tuning 105.0
C086 [AM] terminal offset tuning 0.0
C087 [AMI] terminal meter tuning 80.
C088 [AMI] terminal offset tuning Factory
calibrated
C121 [O] input zero calibration
C122 [OI] input zero calibration
C123 [O2] input zero calibration
C091 Debug mode enable
• 00 Display • 01 No display
00
C101 Up/Down memory mode selection
• 00 Clear last frequency (return to F001)
• 01 Keep last freq. adjusted by UP/DWN
00
C102 Reset mode selection
• 00 Cancel trip state at input signal ON transi-
tion, Stops inverter if in Run Mode
• 01 Cancel trip state at signal OFF transition,
Stops inverter if in Run Mode
• 02 Cancel trip state at input signal ON transi-
tion, no effect if in Run Mode
00
C103 Restart mode after reset
• 00 Restart at 0 Hz
• 01 Resume after frequency matching
00
Func.
Code
Name / Description
Default
Valu e
–FE2/–FU2/
–FR
Set
Valu e
H003/
H203
Motor capacity Factory set
H004/
H204
Motor poles setting
• 2 poles • 4 poles
• 6 poles • 8 poles
4
H006/
H206
Motor stabilization constant 100.
Func.
Code
Name / Description
Default
Valu e
–FE2/–FU2/
–FR
Set
Valu e
