27
C027 [FM] signal selection 7 option codes
available
(see page 34)
00
C028 [AM] signal selection 00
C029 [AMI] signal selection 00
C031 Terminal [11] active state • 00 Normally open
(NO)
•01Normally
closed (NC)
00
C032 Terminal [12] active state 00
C036 Alarm relay terminal
active state
01
C040 Overload signal output mode
• 00 During accel/decel
• 01 During constant speed
01
C041 Overload level setting Rated
current of
each inverter
C042 Frequency arrival setting for accel 0.00
C043 Arrival frequency setting for decel 0.00
C044 PID deviation level setting 3.0
C061 Electronic thermal warning level 80.
C070 Data command method
• 02 Digital operator • 03 RS485
• 04 Expansion card #1
• 05 Expansion card #2
02
C071 Communication speed selection
• 02 (Test) • 03 2400bps
• 04 4800bps • 05 9600bps
• 06 19200bps
04
C072 Node allocation 1.
C073 Communication data length selection
• 07 7-bit data • 08 8-bit data
7
C074 Communication parity selection
• 00 No parity • 01 Even parity
• 02 Odd parity
00
C075 Communication stop bit selection
• 01 1 stop bit • 02 2 stop bits
1
C078 Communication wait time 0.
C081 [O] input span calibration Factory
calibrated
C082 [OI] input span calibration
C083 [O2] input span calibration
Func.
Code
Name / Description
Default
Val ue
–FE2/–FU2/
–FR
Set
Val ue
To Next Page
